COMPASAL
Size | RIM inch | P.R. | L.I/S.R. | Max load (kg) Single Dual | S.W mm | 0.D. mm | T.D. mm | |
12R22.5 | 9.00 | 18 | 152/149L | 3550 | 3250 | 300 | 1080 | 17 |
295/60R22.5 | 9.00 | 18 | 150/147M | 3350 | 3075 | 292 | 916.5 | 14.5 |
295/80R22.5 | 9.00 | 18 | 152/149M | 3550 | 3250 | 292 | 1034 | 14.5 |
315/60R22.5 | 9.75 | 20 | 156/150L | 4000 | 3350 | 313 | 950 | 14.5 |
315/70R22.5 | 9.00 | 20 | 154/150M | 3750 | 3350 | 312 | 1014 | 15 |
315/80R22.5 | 9.00 | 20 | 157/154M | 4125 | 3750 | 310 | 1074 | 15.5 |
11R22.5 | 8.25 | 16 | 148/145L | 3150 | 2900 | 268 | 1054 | 14.5 |
Size | RIM inch | P.R. | L.I/S.R. | Max load (kg) Single Dual | S.W mm | 0.D. mm | T.D. mm | |
12R22.5 | 9.00 | 18 | 152/149L | 3550 | 3250 | 300 | 1080 | 17 |
295/60R22.5 | 9.00 | 18 | 150/147M | 3350 | 3075 | 292 | 916.5 | 14.5 |
295/80R22.5 | 9.00 | 18 | 152/149M | 3550 | 3250 | 292 | 1034 | 14.5 |
315/60R22.5 | 9.75 | 20 | 156/150L | 4000 | 3350 | 313 | 950 | 14.5 |
315/70R22.5 | 9.00 | 20 | 154/150M | 3750 | 3350 | 312 | 1014 | 15 |
315/80R22.5 | 9.00 | 20 | 157/154M | 4125 | 3750 | 310 | 1074 | 15.5 |
11R22.5 | 8.25 | 16 | 148/145L | 3150 | 2900 | 268 | 1054 | 14.5 |
We have different quotation lists and professional purchasing & sales team to answer your request fast.
