Introduce:
1.Less soil compaction.
Forerunner's tire radial structure with wider tread can efficiently reduce the soil compaction caused by increasingly heavy agricultural machines.
2.Longer tire lifetime.
Forerunner developed a high-performance rubber compound and significant strong structure. With this advantages, the tire will last for a longer lifetime and save much more cost.
3.Improved traction.
The new developed tread with richer patterns and wider width bring more strength to your agricultural machines and enhance efficiency for your work.
| SIZE | LOAD | SPEED | OD | SW | RIM | INFLATED PRESSURE | MAX. LOAD |
| INDEX | SYMBOLS | (MM) | (MM) | (KPA) | (KG) | ||
| 20' | |||||||
| 280/85R20(11.2R20) | 112/109 | A8/B | 984 | 283 | W10 | 160 | 1,120 |
| 24' | |||||||
| 280/85R24(11.2R24) | 115/112 | A8/B | 1,086 | 283 | W10 | 160 | 1,215 |
| 320/85R24 (12.4R24) | 122/119 | A8/B | 1,154 | 319 | W10 | 160 | 1,500 |
| 340/85R24 (13.6R24) | 125/122 | A8/B | 1,188 | 343 | W11 | 160 | 1,500 |
| 380/85R24 (14.9R24) | 131/128 | A8/B | 1,256 | 380 | W12 | 160 | 1,950 |
| 380/70R24 | 128/125 | A8/D | 1,190 | 380 | W12 | 160 | 1,650 |
| 420/70R24 | 133/130 | A8/B | 1,248 | 418 | W13 | 160 | 1,900 |
| 136/133 | A8/D | 1,248 | 418 | W13 | 160 | 2,060 | |
| 480/70R24 | 162/162 | A8/B | 1,316 | 479 | W15L | 400 | 4,750 |
| 28' | |||||||
| 320/85R28(12.4R28) | 124/124 | A8/B | 1,255 | 319 | W10 | 160 | 1,600 |
| 340/85R28(13.6R28) | 127/127 | A8/B | 1,289 | 343 | W11 | 160 | 1,750 |
| 380/85R28 (14.9R28) | 133/130 | A8/B | 1,357 | 380 | W12 | 160 | 2,060 |
| 420/85R28 (16.9R28) | 139/136 | A8/B | 1,425 | 418 | W13 | 160 | 2,430 |
| 420/70R28 | 136/133 | A8/D | 1,349 | 418 | W13 | 160 | 2,060 |
| 480/70R28 | 143/140 | A8/D | 1,421 | 479 | W15L | 160 | 2,500 |
| 151/151 | A8/B | 1,421 | 479 | W15L | 320 | 3,450 | |
| 540/65R28 | 145/142 | A8/D | 1,413 | 550 | W18L | 160 | 2,650 |
| 152/149 | A8/D | 1,413 | 550 | W18L | 240 | 3,550 | |
| 600/65R28 | 147/147 | A8/B | 1,491 | 591 | W18L | 160 | 3,075 |
| 154/154 | A8/B | 1,491 | 591 | W18L | 240 | 3,750 | |
| 30' | |||||||
| 420/85R30 (16.9R30) | 140/137 | A8/B | 1,476 | 418 | W13 | 160 | 2,500 |
| 460/85R30 (18.4R30) | 145/142 | A8/B | 1,544 | 455 | W14L | 160 | 2,900 |
| 480/70R30 | 144/141 | A8/D | 1,478 | 479 | W15L | 160 | 2,575 |
| 152/149 | A8/B | 1,478 | 479 | W15L | 320 | 3,550 | |
| IF600/70R30 | 165/165 | A8/D | 1,602 | 591 | DW18L | 240 | 5,150 |
| 540/65R30 | 143/140 | A8/D | 1,464 | 550 | W18L | 160 | 2,725 |
| 153/150 | A8/D | 1,464 | 550 | W18L | 240 | 3,650 | |
| 32' | |||||||
| 800/65R32 | 172/172 | A8/B | 1,853 | 798 | DW25A | 240 | 6,500 |
| 178/178 | A8/B | 1,853 | 798 | DW25A | 240 | 7,300 | |
| 34' | |||||||
| 420/85R34 (16.9R34) | 142/139 | A8/B | 1,578 | 418 | W13 | 160 | 2,650 |
| 147/144 | A8/B | 1,578 | 418 | W13 | 240 | 3,075 | |
| 460/85R34 (18.4R34) | 147/144 | A8/B | 1,646 | 455 | W14L | 160 | 3,075 |
| 480/70R34 | 149/146 | A8/D | 1,580 | 479 | W15L | 240 | 3,250 |
| 155/152 | A8/D | 1,580 | 479 | W15L | 350 | 3,875 | |
| 520/70R34 | 151/148 | A8/D | 1,640 | 516 | W16L | 160 | 3,150 |
| 36' | |||||||
| 320/85R36(12.4R36) | 128/128 | A8/B | 1,455 | 328 | W11 | 160 | 1,800 |
| 38' | |||||||
| 380/80R38 | 138/135 | A8/B | 1,573 | 380 | W12 | 160 | 2,120 |
| 400/75R38 (15.5R38) | 138/135 | A8/B | 1,569 | 394 | W14L | 160 | 2,120 |
| 460/85R38 (18.4R38) | 149/146 | A8/B | 1,747 | 455 | W14L | 160 | 3,250 |
| 520/85R38 (20.8R38) | 155/152 | A8/B | 1,849 | 516 | DW16L | 160 | 3,875 |
| 650/65R38 | 163/163 | A8/B | 1,811 | 645 | DW20A | 240 | 4,875 |
| 520/70R38 | 153/150 | A8/D | 1,749 | 516 | W16L | 160 | 3,350 |
| 580/70R38 | 158/155 | A8/D | 1,827 | 577 | W18L | 160 | 3,875 |
| 710/70R38 | 166/166 | A8/B | 1,959 | 716 | DW23A | 160 | 5,300 |
| 171/171 | A8/B | 1,959 | 716 | DW23A | 240 | 6,150 | |
| 42' | |||||||
| 520/85R42 (20.8R42) | 157/154 | A8/B | 1,951 | 516 | DW16L | 160 | 4,125 |
| 167/164 | A8/B | 1,951 | 516 | DW16L | 320 | 5,450 | |
| 620/70R42 | 163/160 | A8/D | 1,935 | 625 | DW20B | 160 | 4,500 |
| 172/169 | A8/D | 1,935 | 625 | DW20B | 320 | 6,300 | |
| 650/65R42 | 168/165 | A8/D | 1,913 | 645 | DW20A | 240 | 5,150 |
| 170/167 | A8/D | 1,913 | 645 | DW20A | 320 | 6,000 | |
| 710/70R42 | 171/168 | A8/D | 2,061 | 716 | DW23A | 160 | 5,600 |
| 178/173 | A8/D | 2,061 | 716 | DW23A | 160 | 7,500 | |
| 46' | |||||||
| 300/95R46(12.4R46) | 148/148 | A8/B | 1,735 | 298 | W10 | 400 | 3,150 |
| 320/90R46 | 148/148 | A8/B | 1,744 | 312 | W10 | 400 | 3,150 |
| VF380/90R46 | 173 | D | 3,855 | 185 | DW12/DW13 | 440 | 6,500 |
| 480/80R46 | 158/155 | A8/B | 1,936 | 479 | W15L | 240 | 4,250 |
